SoundBarrier Pro Sound CV 8, CV-10, CV-12,CV-15 and 15″/18″ Subs!
These speakers sound amazing! And they represent the highest quality available with state-of-the-art technology. We have heard most every speaker on the market, and used many of them in pro sound applications. In our opinion, there is no better sounding speaker available for this price. Truly THE speaker to get if you are on a budget, We think one would have to spend twice the amount to get better sound. Don’t purchase typical MI type speakers until you have seen the value in THESE Pro Sound speakers!
Simple Customization.
All CV Series loudspeakers are equipped with an easy-to-use signal processor that makes it simple to customize your loudspeakers with the push of a button. Presets customize the CV Series’ response for use in live sound, club, and speech applications. Treble and bass controls let you boost or cut by 10 dB to compensate for room anomalies. Location presets let you optimize performance for pole-mount, bracket, and monitor application
Features
CV-10: Compact and lightweight, CV10 active loudspeakers provide a rich, extended low-end, and natural high-frequency extension in a compact, durable enclosure. Backed by a 700W RMS Class D (Bi-amp) power and enhanced with easy-to-use digital tuning functions, the CV10 gives you all the power and tools you need for both mobile and installed sound. The combination of a 1” exit (1.35” VC) compression driver, 10″ woofer, and a constant directivity waveguide produces coherent 90° x 60° coverage for the listening area with up to 126 dB SPL, distortion-free sound. Ideal for use as a satellite (with subwoofer), stage monitor, or flown, the CV10 blends high-performance and reliability in a compact package. Built specifically for live sound applications, it also features multiple rigging points for fixed installation. The CV series’ built-in DSP processing system is perfectly tuned for each model, delivering absolute clarity and deep, powerful bass response. The rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.
Product Specifications
Acoustic Specifications
FREQUENCY RESPONSE:
60Hz-20kHz (-3dB)
COVERAGE ANGLES:
90° (HORIZONTAL), 60° (VERTICAL)
MAX SPL:
126 DB
IMPEDANCE:
4 OHM
Transducers
LOW FREQUENCY:
10-INCH, 2-INCH VOICE COIL, NEODYMIUM MAGNET
HIGH FREQUENCY:
1-INCH, 1.35-INCH VOICE COIL, COMPRESION DRIVER
Power Section
TOTAL POWER HANDLING:
1400W PEAK
OPERATIONAL VOLTAGE:
100-120V, 50/60Hz
COOLING:
CONVECTION
CONNECTIONS:
AC SOCKET
Processor Section
CROSSOVER POINT:
1.6 kHz
PROTECTION:
DSP DIGITAL LIMITING
CONTROLS:
DSP ROTARY PUSH ENCODER, VOLUME LEVEL
DSP FUNCTIONS:
MODE (NORMAL, LIVE, CLUB, SPEECH)
LOCATION (POLE, MONITOR, BRACKET)
TREBLE & BASS
LED (OFF, ON, LIMIT)
XOVER (150Hz, 120Hz, 100Hz, 800Hz)
Input / Output Section
INPUT SIGNAL:
COMBO XLR / 1/4 INCH JACK
OUTPUT CONNECTORS:
XLR
Construction
COLOR:
BLACK POLYURETHANE PAINT
HANDLES:
TOP WOOD RECESSED HANDLE
CABINET MATERIAL:
15MM PLYWOOD
RIGGING:
M8 FLYING POINTS
35MM PITCH ANGLE POLE-MOUNT
STAGE MONITOR CUT
GRILLE:
1.2 MM STEEL
Standard Compliance
CE MARKING:
YES
ROHS MARKING:
YES
Dimensions
WIDTH: 12.2 INCH / 310 mm
DEPTH: 12.8 INCH / 325 mm
HEIGHT: 22.1 INCH / 560 mm
WEIGHT: 38.6 LB / 17.5KG
